Brazed Single-Crystal Cutting Tools
Finished SCD tools on a carbide shank, for ultra-precision and mirror-finish machining.
The cutting edge is synthetic single-crystal diamond, one continuous crystal free of grain boundaries and pores, brazed onto a carbide shank.
Single-crystal diamond tools are the primary tool in ultra-precision machining, reaching very high workpiece accuracy and very low surface roughness, down to a mirror finish.
- Ultra-high hardness and wear resistance
- Uniform wear resistance and long service life
- Extremely low coefficient of friction and cutting resistance
- Excellent chemical stability and anti-adhesion properties
- Rigid cemented carbide shank
Specifications
| Hardness (diamond) | 90 – 100 GPa |
|---|---|
| Coefficient of friction | 0.1 |
| Elastic modulus (diamond) | 1050 GPa |
| Thermal conductivity at 300 K | > 1800 W·m⁻¹·K⁻¹ |
| Thermal expansion coefficient at 300 K (diamond) | 1.0 ± 0.1 ppm·K⁻¹ |
| Nose radius | 0.01 – 10.0 mm |
| Surface roughness | 10 nm – 2.0 µm |
Reference values from the producer datasheet. Dimensions marked customisable are set per order. Request a quote to have a specification confirmed against your drawing.
Applications
Brazed SCD tools go straight onto the machine for ultra-precision and mirror-finish work.
- Semiconductor: silicon wafer, sapphire substrate and silicon carbide device processing
- Optical: lens and prism processing, optical mould processing, infrared optical components
- Precision instruments: metrology instrument parts, micro-mechanical parts, precision watch parts
- Aerospace: titanium alloy precision parts, magnesium alloy components, composite optical components
